27 ft & 37 ft.
2 – 3 Axle Configurations
24 to 44 cubic yards with planks
KEY FEATURES
¼ Frame Scissor Design
Top Hinge Tailgate with Air Locks,
Air Override Valve for Manual Release
Designed with Hardox Material
Crank Style Dual Landing Gear
Tipping Angle at 47 degree
Bolt on Steel Fenders Front and Rear
Air Ride Suspensions with Dump Valve and Air Gauge rated at 25,000 lbs Capacity.¾ in. Wall Axles with Spring Brakes on all Axles
Dry Slide Bushings and Grease Zerk Pins at all Pivot Points
OPTIONS
Floor Options Available
Tailgate Options – Hi Lift or Dual Swing Gate
Compression Locks
Lights located in Rear Posts
Ashpalt Aprons
Coating Options: Zinc Primer or Other Color Options Available
Mutiple Fender options Available
